Troubleshooting Example

Let's put what we've looked at together into an example and see the steps taken to solve the problem. We start with someone complaining that she is unable to resolve the name www.example.com. We use dig on her machine to verify the behavior, and we received the following output from dig:

$ dig www.example.com. A

; <<>> DiG 9.10.1 <<>> www.example.com. A
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: SERVFAIL, id: 26068
;; flags: qr rd ra; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;www.example.com.		IN	A

;; Query time: 784 msec
;; SERVER: 192.168.1.7#53(192.168.1.7)
;; WHEN: Mon Nov 03 20:00:45 CST 2014
;; MSG SIZE  rcvd: 44

We learned from this output that the recursive name server 192.168.1.7 returned a generic error message when resolving the name www.example.com. The next step is to look at the DNS server configuration on 192.168.1.7 to see how it is configured. Below is an excerpt of named.conf from 192.168.1.7:

options {
    ...
    forwarders {192.168.1.11;};
    forward only;
    ...
};

This tells us that the recursive name server 192.168.1.7 just sends all recursive queries to 192.168.1.11. Let's query 192.168.1.11:

$ dig @192.168.1.11 www.example.com. A

; <<>> DiG 9.10.1 <<>> @192.168.1.11 www.example.com. A
; (1 server found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: SERVFAIL, id: 24171
;; flags: qr rd ra; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 1
...

And we get the same result as when we queries 192.168.1.7, generic failure message, but we also learned that 192.168.1.11 is not authoritative for example.com (no aa flag), so it is getting this response from somewhere else. Below is the configuration excerpt from 192.168.1.11:

options {
    ...
    forwarders {};
    forward only;
    ...
};

zone "example.com" IN {
    type forward;
    forwarders { 192.168.1.13; };
    forward only;
};

At first glance, it may look like 192.168.1.11 is just performing recursion itself, querying Internet name servers directly; however, further down the configuration file, we see the forward zone definition, which tell us that 192.168.1.11 is doing conditional forwarding just for example.com, and it is sending all example.com queries to 192.168.1.13.

We then query 192.168.1.13:

$ dig @192.168.1.13 www.example.com. A

; <<>> DiG 9.10.1 <<>> @192.168.1.13 www.example.com. A
; (1 server found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 35962
;; flags: qr aa rd; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1
;; WARNING: recursion requested but not available

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;www.example.com.		IN	A

;; ANSWER SECTION:
www.example.com.	600	IN	A	192.168.1.100

;; Query time: 4 msec
;; SERVER: 192.168.1.13#53(192.168.1.13)
;; WHEN: Mon Nov 03 20:06:26 CST 2014
;; MSG SIZE  rcvd: 60

Finally! We found the authoritative name server! Now we know our query path looks like this:

Figure 5.1. Query Path

Query Path


But 192.168.1.13 has no trouble answering the query for www.example.com, so the problem might be between 192.168.1.11 and 192.168.1.13? We know there are no firewalls or network devices between 192.168.1.11 and 192.168.1.13 that could intercept packets. Let's query 192.168.1.11 again, but this time, let's purposely turn off DNSSEC validation by using +cd (checking disabled), to see if this error message was caused by DNSSEC validation:

$ dig @192.168.1.11 www.example.com. A +cd

; <<>> DiG 9.10.1 <<>> @192.168.1.11 www.example.com. A +cd
; (1 server found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 58332
;; flags: qr rd ra cd; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;www.example.com.		IN	A

;; ANSWER SECTION:
www.example.com.	562	IN	A	192.168.1.100

;; Query time: 2 msec
;; SERVER: 192.168.1.11#53(192.168.1.11)
;; WHEN: Mon Nov 03 20:01:23 CST 2014
;; MSG SIZE  rcvd: 60

Bingo! So the problem is on 192.168.1.11, and specifically, with DNSSEC validation. Now we can focus our attention on the configuration on 192.168.1.11, examine its logs, check its system time, or check its trust anchors, to see what may be the root cause.

Examining log messages from 192.168.1.11, we notice the following two entries:

error (no valid KEY) resolving 'example.com/DNSKEY/IN': 192.168.1.13#53
error (broken trust chain) resolving 'www.example.com/A/IN': 192.168.1.13#53

So it would appear that on the server 192.168.1.11, there is a broken trust chain. At this point, we can probably conclude the problem is in one of the trusted-keys statements on 192.168.1.11, but let's turn on DNSSEC debug logging (as described in the section called “BIND DNSSEC Debug Logging”), and re-run the dig for www.example.com one more time to see what log messages get generated:

...
validating @0xb4b48968: example.com DNSKEY: attempting positive response validation
validating @0xb4b48968: example.com DNSKEY: unable to find a DNSKEY which verifies the DNSKEY RRset and also matches a trusted key for 'example.com'
validating @0xb4b48968: example.com DNSKEY: please check the 'trusted-keys' for 'example.com' in named.conf.
...

Okay, so we have a confirmed log message telling us to look at 'trusted-keys'. The named.conf on 192.168.1.11 contains the following:

trusted-keys {
    example.com. 257 3 8 "AwEAAbluLK0k3dPKnsJNd5tGbO5bgh7WuXzaSDQVwi/qqPdCR65ZDiin
                          0GTpL++B1iKYDP4rRL/s/2TMppI1fV638f2SuhNQ9zYIuCo/FuHeJB7/
                          DBQ03eJFvN1QHC0we2uUFrXazz8eT9nkI1SUu0fhcs6CA06gGqauDbpU
                          mpM7VUX3";
};

Let's check the authoritative server (192.168.1.13) for the correct key:

$ dig @192.168.1.13 example.com. DNSKEY +multiline

; <<>> DiG 9.10.1 <<>> @192.168.1.13 example.com. DNSKEY +multiline
; (1 server found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 38451
;; flags: qr aa rd; QUERY: 1, ANSWER: 4, AUTHORITY: 0, ADDITIONAL: 1
;; WARNING: recursion requested but not available

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;example.com.		IN DNSKEY

;; ANSWER SECTION:
example.com.		600 IN DNSKEY 256 3 8 (
				AwEAAbluLK0k3dPKnsJNd5tGbO5bgh7WuXzaSDQVwi/q
				qPdCR65ZDiin0GTpL++B1iKYDP4rRL/s/2TMppI1fV63
				8f2SuhNQ9zYIuCo/FuHeJB7/DBQ03eJFvN1QHC0we2uU
				FrXazz8eT9nkI1SUu0fhcs6CA06gGqauDbpUmpM7VUX3
				) ; ZSK; alg = RSASHA256; key id = 4974
example.com.		600 IN DNSKEY 257 3 8 (
				AwEAAb4N53kPbdRTAwvJT8OYVeVhQIldwppMy7KBJ+8k
				Uggx2PU3yP/qlq4Zjl0MMmqRiJhD/S+z9cJLNTZ9tHz1
				7aZQjFyGAyuU3DGW16xfMolcIn+c8TpPCzBOFhxk6jvO
				VLlz+Wgyi1ES+t29FjYYv5cVNRPmxXLRjlHFdO1DzX3N
				dmcUoZ+VVJCvaML9+6UpL/6jitNsoU8JHnxT9B2CGKcw
				N7VaK4l9Ida2BqY3/4UVqWzhj03/M5LK6cn1pEQbQMtY
				R0TNJURBKdK8bH663h98i23tVX0/85IsCVBL4Dd2boa3
				/7HPp7uZN1AjDvcRsOh1mqixwUGmVm1EskDIMy8=
				) ; KSK; alg = RSASHA256; key id = 45319
example.com.		600 IN DNSKEY 256 3 8 (
				AwEAAfbc/0ESumm1mPVkm025PfHKHNYW62yx0wyLN5LE
				4DifN6FzIVSKSGdMOdq+z6vFGxzzjPDz7QZdeC6ttIUA
				Bo4tG7dDrsWK+tG5cm4vuylsEVbnnW5i+gFG/02+RYmZ
				ZT9AobXB5bVjfXl9SDBgpBluB35WUCAnK9WkRRUS08lf
				) ; ZSK; alg = RSASHA256; key id = 60798
example.com.		600 IN DNSKEY 257 3 8 (
				AwEAAb3lVweaj4dA9dvmcwlkaVpJ4/3ccXbRjgV7jqh1
				p0REL8fI0Z42E9SdxdsdTi+2XYcmHDQYEoqwYh70t/4P
				4oObZFIUHl+hhKLdXQNZGtzT0xF60k527N9cHPddoXzg
				AXYBtGLlLMSJcV8s0rw/i+64xNGdRWpFRdo78RhJ5LU3
				1SAPUnhi3OvJgsOpBPntrSyX6iA5ZotitxZJNTqP+Jck
				lhPWFgFOBgdvWJ369BRlDGy/m8+pctypZq1hy7ZteHet
				r55/cLBXY1BEzz3Q8vLUnSOu5An8IF0v2Gt7hOyY3nqu
				bU5vjCbogLj1K5ySBAJbHcCPAFrPGSIfmRize+U=
				) ; KSK; alg = RSASHA256; key id = 40327

;; Query time: 4 msec
;; SERVER: 192.168.1.13#53(192.168.1.13)
;; WHEN: Mon Nov 03 21:51:28 CST 2014
;; MSG SIZE  rcvd: 888

Did you spot the mistake? We have the correct key data in our configuration, but the key type was incorrect. In our configuration, the key was configured as a KSK (257), while the authoritative server indicates that it is a ZSK (256).
